Double door coordination for a simultaneous movement

The double door coordination system allows the simultaneous opening and closing of the two doors while moving only one of them, for a handy and comfortable movement.
Thanks to the ECLISSE extractable track, it can be installed also on already mounted counterframes as well.

This product is available for

• ECLISSE Double
• ECLISSE Luce Double
• ECLISSE Ewoluto Double

Specs

• For wooden doors only.

• Supplied as standard with ECLISSE BIAS, the device that slows down the closing of door panels up to 25+25 kg, whereas for panels over 25+25 kg and up to 50+50 kg the device only slows down the doors.

• Suitable for double door systems with passage width from 600+600 to 1000+1000 mm.

Note: in case of passage size 600+600, the door panels protrude from the jambs so the passage width is reduced.
